Circuit Load Controller
The Avi-on XFAC is a highly capable wireless zone controller with loads of additional features. 110-277V, 16A Lighting rated relay, high capacity 0-10V dimming, and multiple sensor integration options make this a single component solution for an entire zone based control solution.
The XFAC is available in Class I or Class II wiring options. The XFAC is fully networked and integrated with the Avi-on ecosystem and is interoperable with all other Avi-on sensors, wall stations, and fixture controllers.
The XFAC is a sensor integration powerhouse with 2 different sensor inputs: Plug any Avi-on Direct Connect sensor for easy sensor integration, or use the general purpose sensor input with 24VDC power and contact input with third party sensors.
The XFAC includes true measured energy consumption readings every 15 minutes (>0.5% accuracy). Use the XFAC to comply with top tier utility rebate programs and corporate energy management initiatives.
UL 924 Rated
The XFAC is rated as an emergency lighting control appliance. Use to control zones or individual fixtures without adding bypass relays. Trigger emergency status for fixtures across an entire building for applications using Uninterruptible Power Supplies (UPS) or based on triggers from Building Control Systems (BCS). Order the -EM version for emergency mode to be pre configured, or enable/disable emergency mode for any XFAC unit with Avi-on Pro.
Color Changing Capable
Available with 2 0-10V outputs to control color changing (CCT) lights
PARTS & ORDERING
|Part Number||Supply Voltage||Channels||Configuration||Relay|
|AVI-XFAC-16A-1CH-CL1||100 - 277 VAC||Single||Class 1||16 Amp|
|AVI-XFAC-16A-1CH-CL2||100 - 277 VAC||Single||Class 2||16 Amp|
|AVI-XFAC-16A-2CH-CL2||100 - 277 VAC||Dual (CCT)||Class 2||16 Amp|
|AAVI-XFAC-16A-1CH-CL1-EM||100 - 277 VAC||UL 924 Enabled||Class 1||16 Amp|
|AVI-XFAC-16A-1CH-CL2-EM||100 - 277 VAC||UL 924 Enabled||Class 2||16 Amp|
|AVI-XFAC-16A-ENERGY||XFAC without Control Capability - Energy Monitoring of Circuit only|
To order please contact Avi-on sales at (877) AVION-US or firstname.lastname@example.org
for information on becoming an Avi-on partner and order details.
The Avi-on family of products consists of load controllers, sensors, wall stations and connectivity products that work together in one big happy family. Load controllers manage dimming, schedules, scenes, groups/zones and more while the sensors are able to detect motion with all new state-of-the-art features. These products work seamlessly with the Av-ion cloud to provide a robust wireless ecosystem.
