Avi-on Fixture &
Zone Controllers

Direct Connect
low Voltage Fixture Adapter (LVFA)

The LVFA series fixture adapter mounts inside lighting fixtures proving addressability for each luminaire. All fixture adapters are part of the Avi-on® Bluetooth® with Mesh product ecosystem supported by the Avi-on mobile app, commissioning tools and cloud IoT Services.

Direct Connect
Internal Fixture Adapter (IFA)

Avi-on’s Internal Fixture Adapters provide single or dual channel (CCT) 0-10V controls for dimming, zero-cross switched AC power, energy monitoring, and Direct Connect™ sensor input. Non-volatile memory preserves device settings, including groups and schedules. The Fixture Adapter is designed to support any fixture, regardless of driver type.

Direct Connect
Avi-on XPP Zone Control

Avi-on’s XPP provides single or dual 0-10V circuit level controls for dimming, zero-cross switched AC power, energy monitoring, and sensor inputs. Non-volatile memory preserves device settings, including groups and schedules. It includes a 16A full circuit high voltage relay and is designed for junction box mounting installation.

Avi-on Legacy
Fixture Adapter

Avi-on Fixture Adapters are packaged DC powered adapters that enable Bluetooth® wireless lighting controls for on/off, dimming and tunable white functions. The compact design incorporates the antenna and all controls needed to interface with the Avi-on App, providing a ready Powered by Avi-on™ platform that supports grouping, scheduling, timers and scene management.

Avi-on Legacy Relay Fixture Adapter

Avi-on Relay Fixture Adapters provide one or two channels of 0-10V output for dimming, and a relay control output. Relay Fixture Adapters may be placed inside an LED lighting fixture to enable wireless switching and dimming with drivers that required a power disconnect to fully turn off. The relay adaptor is generally coupled with the 25-700 relay power supply to create a full AC to driver control solution.
