XFAC UL 924 Mode
UL 924 XFAC FEATURES
The Emergency mode XFAC is a highly capable wireless zone controller that also provides UL 924 2022 emergency fixture compliance by turning the light on and setting maximum dim value upon receiving a wireless signal from the AVI-SIM-UL924-OA. 110-277V, 16A Lighting rated relay, high capacity 0-10V dimming, and multiple sensor integration options make this a single component solution for an entire zone based control solution for normal power, and an emergency shunt relay override for emergency fixtures.
Any Avi-on XFAC can be enabled in UL 924 mode in the field. This data sheet is provided for wiring and specification and is available for ordering pre enabled for emergency mode.
Easy and Cost Effective Emergency Lighting Solution
Simply install one AVI-SIM-UL924-OA per transfer switch, or UPS to detect the absence of normal power.The Avi-on XFAC in emergency mode will receive the wireless signal, turn on the emergency fixture(s) and set maximum dimming for the duration of the loss of normal power. The Avi-on solution eliminates the need for separate UL924 shunt relays. Designed to complement UL 1008 listed transfer switches or Uninterruptible Power Supplies (UPS) with built in test modes.
The XFAC is available in Class I or Class II wiring options. The XFAC is fully networked and integrated with the Avi-on ecosystem and is interoperable with all other Avi-on sensors, wall stations, and fixture controllers.
The XFAC is a sensor integration powerhouse with 2 different sensor inputs: Plug any Avi-on Direct Connect sensor for easy sensor integration, or use the general purpose sensor input with 24VDC power and contact input with third party sensors.
The XFAC includes true measured energy consumption readings every 15 minutes (>0.5% accuracy). Use the XFAC to comply with top tier utility rebate programs and corporate energy management initiatives.
Color Changing Capable
Available with 2 0-10V outputs to control color changing (CCT) lights
UL 924 XFAC
PARTS & ORDERING
|Part Number||Supply Voltage||Channels||Configuration||Relay|
|AVI-XFAC-16A-1CH-CL1-EM||100 - 277 VAC||Single||Class 1, UL 924 Enabled||16 Amp|
|AVI-XFAC-16A-1CH-CL2-EM||100 - 277 VAC||Single||Class 2, UL 924 Enabled2||16 Amp|
|AVI-XFAC-16A-CCT-CL2-EM||100 - 277 VAC||Dim & Color Channels(CCT)||Class 2, UL 924 Enabled||16 Amp|
|AVI-XFAC-16A-WC-CL2-EM||100 - 277 VAC||Two Drivers (Warm/Cool (W/C)||Class 2, UL 924 Enabled||16 Amp|
The Avi-on family of products consists of load controllers, sensors, wall stations and connectivity products that work together in one big happy family. Load controllers manage dimming, schedules, scenes, groups/zones and more while the sensors are able to detect motion with all new state-of-the-art features. These products work seamlessly with the Av-ion cloud to provide a robust wireless ecosystem.
